標準規格
Specification | 選用配備
Options |
減速馬達
Reduce Speed Motor | 1/4Hp(0.2KW)1/165 220/380V | 1.CE規格裝置
CE Specification Device | 1.簡單型CE屑口裝置
Simple CE device of exit |
輸送鏈距
Pitch of Chain | R2050 P=31.75mm | 2.全罩式CE屑口裝置
Fullcover CE device of exit |
鏈板寬度
Hined beit Width | 175,150-600（每隔50mm一種規格） | 2.手動控制裝置
Manual Conteol Device | 1.標準型正逆?？刂?/span>
Standard emergent stop |
175,150-600（there is one king of | 2.CE規格正逆停緊?？刂?/span>
CEspec standerd emergent stop |
specification every 50mm) |
站鈑速度
Hinged Belt WIdth | 每六個鏈距1片
One Pieces for every six pitch | 3.各式遠端控制盒
Various far lerminal control boxes |
輸送速度
Conveyor speed | 1.3-1.5M/min(50/60HZ) | 4.各式電氣蛇復纜線
Various romote contriller cable lines |
安全裝置
Safety Devie | HTL-350-2 | 5.扭力過載停止裝置
Torque linit device |
輸送仰角
Angle Of Conveyor | 60° | 6.防止卷入停止裝置
Prevent chips roll up device |
